oktalite

LOBU

Small but wow!

L

LOBU

LOBU brings reduced luminaire design in a small structural shape with powerful lighting characteristics onto the sales floor. The best possible light distribution in every tilted position systematically sets the scene for the goods. Colour combination possibilities for the housing and the reflector ring provide design freedom for more individuality.

LOBU in use

With its clear design, the luminaire steps back visually and places the lighting task at the centre of things. Efficient facetted reflectors ensure the best possible light distribution in every tilted position. The spotlight is available with six white light colours, and special spectrums for Food, for all goods segments. The customised choice of colour for the reflector ring in white or black permits a bi-colour luminaire design.

Lightquality – inspired by the sun

Lighting, as natural and atmospheric as the afternoon sun on a clear spring day, at the same time with intense and brilliant colour:
this performance is our inspiration for the optimization of holistic lighting for retail.

FIND OUT MORE

The chip in an LED (light-emitting diode) converts electric energy via electroluminescence into light. The complex and customized interplay between semi-conductor crystal and the fluorescent conversion layer above it defines the LED module as a "package". The customized composition of this package also plays a part in deciding on the quality, colour rendition, colour saturation and depth of field of the lighting. BRILLIANT COLOUR and EFFICIENT WHITE: our LED modules in unprecedented specification are the result of intensive research and development.

The colour rendering index CRI comprises, according to DIN 6169, only eight specified test colours consisting of pastel shades between antique rose and lilac. This so-called Ra was later supplemented in order, for example, to be able to better assess a saturated red (R 9): The extended CRI (Re) therefore includes six additional colours: red, yellow, green, blue, plus pink (flesh colour) as well as leaf green. The ideal value for the most natural colour rendering is in the case of the CRI generally 100. Already on the basis of the two indices Ra and Re it becomes clear: equal or similar CRI values do not automatically mean that the colour rendering of a light source is equal or similar. It is only the graph that makes the differences clear in detail.

white

medium

dark

Color:

Can be tiilted through 220" and turned through up to 355°

Large lumen package with low size

Front ring optionally in black available

Five different segmented reflectors for optimum light distribution

LEDIQ for intelligent lighting management

Technical Specifications & Downloads

Please select a light source

Application areas Accent lighting
Lumen category 1500 lm - 4000 lm
Light colour 2700 K, 3000 K, 3000 K - Efficient White, 3000 K - Brilliant Colour, 3500 K, 4000 K , B+V+C, M, M+F
Optic 3D facetted reflectors
Supply unit Driver
Lighting controls on request
Material Die-cast aluminium
Luminaire colour RAL 9005 jet black
RAL 9006 white aluminium
RAL 9016 traffic white
Weight Approx. 1.3 kg
Application areas Accent lighting
Lumen category 2000 lm - 4000 lm
Light colour 2700 K, 3000 K, 3000 K - Efficient White, 3000 K - Brilliant Colour, 3500 K, 4000 K , B+V+C, M, M+F
Optic 3D facetted reflectors
Supply unit DALI driver
Lighting controls DALI DT6
Installation Recommended for new installation.
Mounting Type: Global DALI
Material Die-cast aluminium
Luminaire colour RAL 9005 jet black
RAL 9006 white aluminium
RAL 9016 traffic white
Weight Approx. 1.3 kg

130

0

lm/W

Energy efficiency

LOBU has been changed over to the latest LED generation and has an efficiency of 130 lumens per watt.

* The comparative values are based on the uniform basis: colour temperature 4000 K and lumen class 4000 lm.

LOBU references

Carrefour

Rabat, Morocco

View reference

Under Armour

Pretoria, South Africa

View reference

Medimax

Weinheim, Germany

View reference

Toys World

Gütersloh, Germany

View reference


The Lobu product family

LOBU

recessed luminaire


Driver separate


Can be turned through up to 355° and tilted through 140°


View product

LOBU

track light


Driver integrated


Can be turned through up to 355° and tilted through 220°


View product
